YSB100 Excavator Jack Hammer Attachment 100mm Chisel Diameter
| Place of Origin | GUANGZHOU |
|---|---|
| Brand Name | FANGBANG |
| Model Number | YSB100 |
| Minimum Order Quantity | negotiable |
| Price | negotiable |
| Packaging Details | standard packing |
| Delivery Time | 5-8 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 1000 Piece/Pieces per Week |
Product Details
| Body Weight | 479kg | Impact Frequebcy | 350-700 Bpm |
|---|---|---|---|
| Chisel Diameter | 100mm | Suitable Excavator(ton) | 10-15 Tons |
| Name | Excavator Jackhammer Attachment | Type | Hydraulic Breaker |
| High Light | YSB100 Excavator Jack Hammer,100mm Chisel Diameter Excavator Jack Hammer |
||
Product Description
YSB100 excavator jackhammer attachment best hydraulic hammers for excavators
Product model and relevant data
| Specname | Unit | YSB40 | YSB53 | YSB68 | YSB75 | YSB85 | YSB100 | YSB125 |
| Body weight | kg | 53 | 89 | 156 | 214 | 282 | 479 | 620 |
| size | mm | 918*176*360 | 1178*230*500 | 1373*295*772 | 1515*295*735 | 1735*390*910 | 1900*390*910 | 2286*480*1120 |
| 1086*156*189 | 1344*235*370 | 1684*350*486 | 1706*390*486 | 2120*438*570 | 2387*450*570 | 2673*498*600 | ||
| 1190*260*295 | 1417*350*305 | 1660*328*486 | 1712*328*486 | 2074*438*570 | 2345*440*570 | 2578*498*625 | ||
| Operating pressure | Kg/cm² | 90-102 | 90-120 | 110-140 | 120-150 | 130-160 | 150-170 | 150-170 |
| Hydraulic flow range | L/min | 15-25 | 25-50 | 40-70 | 50-90 | 60-100 | 80-110 | 90-120 |
| Diameter of house | inch | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 |
| Diameter of tool | mm | 40 | 53 | 68 | 80 | 85 | 100 | 125 |
| Impact frequebcy | bpm | 800-1400 | 600-1100 | 500-900 | 400-800 | 400-800 | 350-700 | 350-650 |
| Suitable carrier | ton | 0.8-2.5 | 2.5-4.5 | 4-7 | 6-9 | 7-14 | 10-15 | 15-18 |
Product features of excavator breaker hammer
·Designed crushing technology
·Heat treatment technology: enhance heat resistance and wear resistance.
·Low fuel consumption design: reduce the volume of oil cylinder and fuel consumption under the condition of constant oil pressure.
·Durability design of movement: the original imported Korean movement is adopted, and the piston annular oil passage is designed to reduce resistance and make the piston cylinder more durable.
Mining: Breaking ore rocks, Second time crushing, Screen crushingProduct application range
Metallurgy: Steel ladle and slag cleaning, Fumace dismantling, Equipment foundation removal
Public road: Highway repair, Cement pavement broken, Foundation excavation
Railway: Mountain and tunnel excavation, Road and bridge demolition, Subgrade compaction
Building: Demolition of old buildings, Broken reinforced concrete
Ship repairing and Construction: Removing clam and rust
Others: Breaking ice, Breaking frozen soils, Sand mold Vibration
Our company main products is hydraulic breakers, underwater breakers, and breaker parts and multifunctional attachments for Shuishan, Furukawa, Engineers, and Dongkong. At the same time, special devices for various working conditions can be tailored according to the customer's operating environment requirements.
