25L/Min Excavator Breaker Hammer 53kg Hydraulic Hammer For Mini Excavator
| Place of Origin | GUANGZHOU |
|---|---|
| Brand Name | FANGBANG |
| Minimum Order Quantity | negotiable |
| Price | negotiable |
| Packaging Details | standard packing |
| Delivery Time | 5-8 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 1000 Piece/Pieces per Week |
Product Details
| Hydraulic Flow Range | 15-25L/Min | Impact Frequency | 800-1400 Bpm |
|---|---|---|---|
| Diameter Of Hose | 1/2 Inch | Suitable Excavator | 0.8-2.5 Ton |
| Body Weight | 53kg | Warranty | 1 Year |
| High Light | 25L Min Excavator Breaker Hammer,53kg hydraulic hammer for mini excavator,53kg Excavator Breaker Hammer |
||
Product Description
25L/Min Excavator Breaker Hammer Powerful Percussion For Municipal Gardens
What is the Hydraulic Breaker?
Hydraulic breaker is a powerful percussion hammer fitted to an excavator for demolishing concrete structures or rocks.
Application of Hydraulic Breaker Hammer
1.Mining: Mountains, mining, crushing, secondary crushing.
2.Metallurgy, slag cleaning, ladle furnace demolition, demolition equipment foundation body dissatisfied.
3.Railway: tunnel, bridge, mountain down.
4.Highway: highway repair, cement pavement broken, foundation excavation.
5.Municipal gardens: concrete crushing, water,electricity, gas engineering construction, the transformation of the old city.
6.Building: the old building demolition, reinforced concrete broken.
7.The ship hull in mussels.
8.Other: ice breaking, breaking the Vibrating Sand.
Mining:Mining,second-time breaking
Metallurgy:Clearing slag,Demolition of furnace and foundation
Road:Repairing,Breaking,Foundation work
Railway:Tunneling,Demolition of bridge
Construction:Demolition of building and reinforced concrete
Ship repairing:Clearing clam and rust from the hull
others:Breaking Frozen mud
Metallurgy:Clearing slag,Demolition of furnace and foundation
Road:Repairing,Breaking,Foundation work
Railway:Tunneling,Demolition of bridge
Construction:Demolition of building and reinforced concrete
Ship repairing:Clearing clam and rust from the hull
others:Breaking Frozen mud
Structure
Patented body design
Inner valve
Quiet operation
Fuel saving
Low maintenance cost
Smart bracket design
Energy recovery system
Various working tools
Inner valve
Quiet operation
Fuel saving
Low maintenance cost
Smart bracket design
Energy recovery system
Various working tools
Product Description
Application
|
model
|
unit | DEHN1400 | DEHN1550 | DEHN1650 | DEHN1750 |
| operation weight(side/top/box) | kg | 1774/2059/1866 | 2577/2745/2968 | 2751/3156/2916 | 3905/4057/3902 |
| length(side/top/box) | mm | 2480/2866/2793 | 2776/3102/3075 | 2820/3285/3337 | 3184/3812/3723 |
| working flow rate | 1iter/min | 120-180 | 180-240 | 200-260 | 200-260 |
| oil relief pressure | kg/cm² | 210 | 230 | 240 | 240 |
| working pressure | kg/cm² | 160-185 | 170-200 | 160-180 | 180-200 |
| impact rate | bpm | 350-500 | 300-450 | 250-400 | 200-350 |
| chisel diameter | mm | ¢140 | ¢1550 | ¢162 | ¢1750 |
| oil pipe nominaldiameter | inch | 1 | 1 | 5/4 | 5/4 |
| back head pressure | kg/cm² | 16±0.5 | 16±0.5 | 16±0.5 | 16±0.5 |
| Accumulator pressure | kg/cm² | 60 | 60 | 60 | 60 |
| Applicable Excavator weight | ton | 18-26 | 27-36 | 30-40 | 35-40 |
| Applicable Bucket | m³ | 0.9-1.2 | 1.0-1.4 | 1.6-2.2 | 1.6-2.2 |
| Value Ass'y Position | internal | internal | internal | internal |
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swivel joint, fuel tank, filter, boom, arm, bucket etc.
For more information please contact with our company.
